G305-130F13A34E-1FU
Yutai
The Car Door Lock with Rod And Positioning Right Outlet (300) represents the pinnacle of automotive security engineering, designed to deliver a reassuring, solid tactile feedback with every actuation. When integrated into a vehicle's door assembly, this locking mechanism provides an immediate mechanical response that communicates safety and precision to the end-user. Crafted to eliminate the frustrating sticking and sluggish movement common in inferior components, it ensures a seamless transition between locked and unlocked states. The robust metal rod feels exceptionally sturdy, engineered to translate mechanical force with zero lost motion, while the precise positioning of the right outlet guarantees an exact fit within the door panel cavity. By utilizing this advanced locking system, assembly lines and repair facilities can drastically reduce installation friction, ensuring that every vehicle leaving the bay operates with factory-level perfection. The sealed architecture repels moisture and airborne particulates, meaning the crisp, responsive action remains consistent whether operating in a humid coastal city or a freezing alpine environment. This translates directly to fewer maintenance claims, higher client satisfaction, and a reputation for uncompromising reliability in your component offerings.
Parameter | Specification |
|---|---|
Product Name | Car Door Lock with Rod And Positioning Right Outlet (300) |
Model | G305-130F13A34E-1FU |
Brand | Yutai |
Standard Specification | ENEC/CQC 2A 24VDC 4A 12VDC 12VDC |
Operating Temperature | -40℃∽+85℃ |
Mechanical Life | 500000 cycles |
Electrical Life | 10000 cycles |
Elevate your automotive component portfolio with a locking mechanism engineered for absolute operational certainty. This product merges structural integrity with advanced micro-switch technology to minimize maintenance overhead.
Precision Actuation: Delivers a highly responsive, tactile feedback that ensures the locking state is immediately engaged and secure, providing a premium feel to the end-user.
Integrated Rod Design: The pre-assembled high-tensile rod eliminates the need for secondary component sourcing, streamlining your assembly process and reducing inventory complexity.
Right Outlet Positioning: Specifically calibrated for right-side outlet configurations, this design prevents alignment errors during rapid installation, ensuring a perfect fit every time.
Acoustic Excellence: Engineered to produce a muted, solid sound upon locking, enhancing the perceived acoustic quality and luxury feel of the vehicle's interior cabin.
Sourcing components that fit perfectly on the first try is critical for maintaining efficient production and repair schedules. This door lock assembly is meticulously calibrated to meet stringent Original Equipment (OE) standards, ensuring it drops into existing door cavities without the need for structural modifications.
Plug-and-Play Architecture: Designed for immediate integration, this lock assembly drastically reduces labor time on the assembly line or in the repair bay, allowing technicians to secure the component swiftly and move to the next phase of production.
Direct Replacement Capability: It mirrors the exact dimensions and mounting points of factory originals. This precise engineering eliminates the need for custom fabrication, adapter plates, or forced alignments during the installation process.
Dimensional Accuracy: The right outlet and rod length are machined to micro-millimeter tolerances. This ensures the mechanism operates smoothly without binding against window tracks, acoustic insulation, or interior door panels.
Universal Electrical Interface: Seamlessly connects with standard automotive wiring harnesses, guaranteeing instant electrical communication with the central locking system without requiring complex rewiring or pin reconfigurations.
Vehicle doors are inherently hostile environments, constantly subjected to driving rain, fine road dust, and severe temperature fluctuations. This micro-switch locking system is fortified with superior sealing technology.
Extreme Temperature Resilience: Operates flawlessly in a staggering range from -40℃ to +85℃, guaranteeing reliable security and swift actuation in both arctic freezes and extreme desert heatwaves.
Moisture Repulsion: Advanced elastomeric seals prevent condensation and rainwater from compromising the internal electrical contacts, maintaining optimal conductivity in wet conditions.
Particulate Isolation: The dustproof housing blocks microscopic road grit from entering the mechanism, preventing premature abrasion of moving parts and ensuring long-term smooth operation.
Frequent actuation is the reality for any automotive door lock. To protect your brand's reputation and eliminate costly post-installation failures, this mechanism is over-engineered to outlast the vehicle's standard life cycle.
500,000 Cycle Mechanical Life: The physical levers, springs, and rod are rigorously tested to endure half a million locking events without structural degradation, bending, or loss of mechanical tension.
10,000 Cycle Electrical Life: The internal micro-switch contacts resist electrical arcing and carbon buildup, ensuring consistent, uninterrupted electrical continuity for tens of thousands of uses.
Fatigue-Resistant Mechanics: Internal tensioning components retain their original elasticity over years of use, preventing the lock from feeling spongy, weak, or unresponsive over time.
Trust in a component is built on verifiable, third-party validation. We understand that large-scale procurement demands absolute adherence to global safety and electrical standards.
ENEC & CQC Certified: Complies with stringent European and international safety standards for electromechanical switches, guaranteeing reliable performance and safe integration across global markets.
Flame Retardant Architecture: Constructed from specialized polymers that resist ignition and self-extinguish, adding a critical layer of thermal safety to the vehicle's complex electrical system.
ISO Compliant Manufacturing: Produced in a facility governed by strict quality management systems, ensuring every single unit mirrors the exact specifications and performance metrics of the master prototype.
The tactile superiority of this door lock is a direct result of uncompromising material selection and masterful engineering, creating a mechanism that feels exceptionally well-crafted.
High-Conductivity Contacts: Internal switching mechanisms utilize premium metal alloys to ensure instantaneous electrical transmission, eliminating signal lag between the user command and the lock actuation.
High-Strength Metal Rod: Forged to resist bending and torsional stress, the connecting rod delivers immediate mechanical force without flexing, ensuring a solid transfer of kinetic energy.
Precision Outlet Molding: The positioning right outlet is cast with zero flash or sharp burrs, allowing for smooth, frictionless interaction with adjoining mechanical linkages inside the door panel.
Ultimately, a door lock must provide unshakeable security and intuitive operation. This product transforms the user experience by delivering a rapid, authoritative locking action.
Instantaneous Response: The integrated micro-switch triggers the actuator with zero perceptible delay, locking or unlocking the door the exact millisecond the electrical command is sent.
Anti-Jamming Geometry: The internal mechanical layout is specifically designed to prevent the lock from sticking halfway, ensuring definitive, absolute locked or unlocked states every time.
Secure Physical Latching: Provides a firm physical barrier that resists forced entry and prevents accidental unlocking during severe road vibrations, rough terrain, or unexpected impacts.
Partnering with Ningbo Yutai Electronics Co., Ltd. means aligning with a manufacturer dedicated to engineering excellence since 2016. We specialize in transforming complex electromechanical requirements into highly reliable solutions.
Dedicated Manufacturing Expertise: Years of specialized focus on micro switches and automotive locking mechanisms guarantee a product born from deep industry knowledge and refined engineering practices.
Scalable Production Capacity: Our advanced facilities are equipped to handle high-volume orders with consistent precision, ensuring your supply chain never faces unexpected inventory shortages or delays.
Stringent Quality Control: Every production batch undergoes rigorous automated and manual testing before leaving our facility, virtually eliminating defect rates and ensuring out-of-the-box reliability.
Global Export Readiness: Experienced in international logistics and compliance, we deliver your components safely, securely, and strictly on schedule, regardless of your geographic location.
Navigating the technical specifications of automotive locking mechanisms requires precise information. Below, we address the most critical operational and integration questions to assist your engineering teams.
Q1: How does the positioning right outlet improve the assembly process?
A1: The specifically engineered right outlet acts as a built-in alignment guide. It ensures the connecting rod interfaces with the door latch at the exact required angle, eliminating the need for manual adjustments and significantly speeding up the installation timeline.
Q2: Can this lock mechanism withstand the high-pressure washing systems used in vehicle detailing?
A2: Yes. The unit features a highly robust waterproof and dustproof architecture. The internal micro-switch is hermetically shielded against moisture ingress, ensuring that neither high-humidity environments nor direct water exposure will compromise its electrical integrity.
Q3: What makes the 500,000-cycle mechanical life a critical metric for this component?
A3: Door locks are subjected to constant, daily use. A 500,000-cycle rating guarantees that the internal springs, levers, and the external rod can endure years of high-frequency actuation without suffering from metal fatigue, thereby drastically reducing replacement rates.
Q4: Is the G305-130F13A34E-1FU model compatible with 24V commercial vehicle systems?
A4: Absolutely. The switch is ENEC/CQC certified to handle 2A at 24VDC, as well as 4A at 12VDC. This dual-voltage capability makes it highly versatile, allowing it to be integrated into both standard passenger cars and heavy-duty commercial vehicles.
Q5: How does the extreme temperature rating (-40℃ to +85℃) affect the lock's performance?
A5: Standard plastics and lubricants can freeze or melt in extreme climates, causing lock failure. Our mechanism utilizes advanced temperature-stable polymers and specialized synthetic grease, ensuring the actuation remains smooth and instantaneous whether in freezing arctic conditions or extreme desert heat.
Q6: Does the integrated rod require additional lubrication before installation?
A6: No additional lubrication is required. The rod and internal mechanisms are pre-treated with high-grade, temperature-resistant lubricants at our facility, ensuring it is completely ready for immediate plug-and-play installation upon unboxing.
