G19-082LRB1AB
Yutai
Our G10 series micro switches have the following features: Small size: Compact structure and light weight make it easy to install in equipment with compact space. Full safety certification: Usually obtain major global safety certifications such as ENEC, UL, CQC, etc. Long life and reliability: Long mechanical and electrical life, stable performance, and can withstand frequent operation. Various specifications: There are various rated currents, voltage values, various contact forms, operating handle types and terminal blocks to meet different needs. High sensitivity: It can respond quickly to tiny external forces, achieve precise triggering, and quickly and accurately control the on and off of the circuit. Good feel: Reasonable internal structure design can provide crisp touch and clear feedback
Standard | Specification |
ENEC/CQC | 0.1A 125VAC 48VDC |
UL | 0.1A 125VAC 48VDC |
ENEC/CQC | 1A/3A 125VAC |
UL | 1A/3A 125VAC |
Operating Temperature | -40℃∽+85℃ |
Mechanical Life | 1000000 cycles |
Electrical Life | 50000 cycles |
