G5T10-A001U
Yutai
The standard model G5T10-A001U is specially optimized for dishwasher door interlock and safety protection control, with a compact enclosed structure, fast snap-action response, and ultra-high operational stability. It has passed global mainstream safety certifications, with rich customizable configurations, making it the core safety control solution for home appliance manufacturers, commercial kitchen equipment producers, and industrial control system integrators.
The enclosed housed micro switch for dishwashers adopts a professional enclosed housing design, which effectively blocks water vapor, moisture, and detergent residue from entering the switch interior, perfectly adapting to the high-temperature, high-humidity, and corrosive working environment inside dishwashers. This design greatly reduces the failure rate caused by environmental erosion, ensuring long-term stable operation of the safety system during frequent washing cycles.
This safety interlock micro switch for dishwashers features a precision snap-action mechanism with tiny contact gap and small travel, delivering high sensitivity and rapid on-off switching. It can accurately trigger the safety interlock function when the dishwasher door is opened or closed, preventing equipment misoperation and potential safety hazards. With a mechanical life of 100,000 cycles and an electrical life of 50,000 cycles, it fully meets the high-frequency use requirements of household and commercial dishwashers.
The safety certified home appliance micro switch complies with ENEC, UL, and CQC international safety standards, meeting the market access requirements of global home appliance markets. It provides a wide range of current rating options from 0.1A to 26A, adapting to different power specifications of household and commercial dishwashers. The operating temperature range covers -25℃ to +150℃, maintaining stable performance in the high-temperature washing and drying cycles of dishwashers.
To meet the diversified installation needs of different dishwasher models, we provide a complete range of terminal connection solutions and various operating handle types for the customizable housed micro switch. Whether for built-in door interlock structures or external safety trigger systems, the switch can be seamlessly integrated into your existing equipment design, shortening your product development cycle and reducing assembly costs.
Model | Standard | Specification |
|---|---|---|
G5S05 | ENEC/CQC | 0.1A 125/250VAC 48VDC 5(2.5)A 125/250VAC |
G5S05 | UL | 0.1A 125/250VAC 48VDC 5A 125/250VAC 48VDC 1/10HP |
G5T08 | ENEC/CQC | 8(10)A 250VAC |
G5T08 | UL | 10.1A 250VAC 1/2HP |
G5T10 | ENEC/CQC | 10(3)A 125/250VAC 10(4) 250VAC |
G5T10 | UL | 10A 125/250VAC 1/2HP 11A 125/250VAC 1/3HP |
G5T16 | ENEV/CQC | 16(4)A 250VAC |
G5T16 | UL | 16A 125/250VAC 1/2HP |
GTT22 | ENEV/CQC | 22(8)A 250VAC |
G5T22 | UL | 22A 125/250VAC 1HP |
G5T26 | ENEV/CQC | 26(10)A 250VAC |
Operating Temperature | -25℃∽+85℃ -25℃∽+125℃ -25℃∽+150℃ | |
Mechanical Life | 100000 cycles | |
Electrical Life | 50000 cycles | |
The G5 Housed Micro Switch is corely applied to dishwasher safety systems and door interlock control of household and commercial dishwashers. It is also widely used in electric faucet controls, egg steamer safety triggers, smart trash bin actuators, water dispenser control systems, car gear shift handball mechanisms, electric wheelchair control devices, medical surgical guns, and other fields that require high-reliability enclosed safety switches.
We provide professional customization and bulk procurement solutions for home appliance manufacturers, commercial kitchen equipment producers, and industrial bulk procurement clients. Our customization services cover housing structure, operating handle type, terminal connection form, electrical parameters, and temperature resistance grade, fully adapting to the unique design requirements of your dishwasher safety system. For bulk orders, we offer stable mass production capacity, 100% full-inspection quality control, exclusive one-to-one technical support, and flexible delivery arrangements, providing you with a reliable, efficient, and cost-effective procurement solution for large-scale production.
The G5 Housed Micro Switch is professionally designed and optimized for dishwasher safety system micro switch applications, with the standard model G5T10-A001U specially used for dishwasher door interlock and safety protection control.
Yes. The switch adopts an enclosed housing design to prevent water vapor and moisture intrusion, and offers three optional temperature grades with an operating range up to -25℃∽+150℃, fully adapting to the high-temperature washing and high-humidity environment inside dishwashers.
Our G5 Housed Micro Switch has obtained ENEC, UL, and CQC global authoritative safety certifications, fully complying with the market access standards of major global home appliance markets.
Yes. We provide full-process customization services, including housing structure, operating handle, terminal type, and electrical parameters, to perfectly match the installation and control needs of different dishwasher models.
The switch has a mechanical life of up to 100,000 cycles and an electrical life of up to 50,000 cycles, which can fully meet the high-frequency daily use requirements of household and commercial dishwashers.
