1: Compact structure with tiny contact gap. Fast action, high sensitivity, and small travel characteristics.
2: High durability, high reliability.
3: Equipped with global safety certifications.
4: Complete range of terminal connections.
5: Available in various temperature grades: 25T85, 25T125, 25T150.
6: Fitted with various types of operating handles.
7: Widely used in household appliances, electronic equipment, automation equipment, medical devices, automotive electronics, power tools, and instrumentation fields.
Operating Speed | 0.1 mm ~ 1 m/s (depending on actuator type) | |
Operating Frequency | Mechanical | 60 times/min |
Electrical | 15 times/min | |
Insulation Resistance | ≥ 100 MΩ (500VDC) | |
Contact Resistance | ≤ 100 mΩ（Initial value） | |
Dielectric Strength Dielectric Strength | Between terminals of opposite polarity | AC 1000V, 50/60Hz, 1 min |
Between live metal parts & accessible dead metal parts (case / terminals) | AC 1500V, 50/60Hz, 1 min | |
Vibration Resistance | 10 ~ 55 Hz, 1.5 mm double amplitude | |
Shock Resistance | Destruction ：(operating force > 1.0N)1000 m/s² (approx. 100g) max. (operating force ≤ 1.0N)400 m/s² (approx. 40g) max. Malfunction： (operating force > 1.0N)200 m/s² (approx. 20g) max. (operating force ≤ 1.0N)100 m/s² (approx. 10g) max. | |
Endurance (Life) | Mechanical≥ 10,000,000 cycles or 1,000,000 cycles | |
Electrical≥ 50,000 cycles or 100,000 cycles | ||
Weight | Approx. 6.2 g (no actuator lever) | |
